6 tools

Hedge, tree, weed and fence maintenance

45°

Automatic break-back system

25 l/min

Minimum oil flow required for vehicle

2-years warranty

High quality materials that ensure a long life

Overview

Multi Carrier Puma 2303

Extend the horizontal reach of your vehicle with our Multi Carrier Puma 2303 and reduce the time spend on landscape maintenance tasks.

The Multi Carrier Puma 2303 can easily be mounted on smaller vehicles, such as skid steer loaders and compact tractors with a minimum weight of 1,200 kg (2,646 lb). Grass mowing, hedge cutting, shelterbelt maintenance and cleaning of pavements are easily done with this small, versatile and flexible machine.

Specifications

Puma 2303

Reach from center of vehicle to end of tool	1.8 m	5'11"
Transport width	1.3 m	4'3"
Required hydraulic connections	1 x double acting + 1 x drain
Minimum oil flow	25 l/min @ 180 bar	6.6 gpm @ 2611 psi
Weight without brackets	110 kg	243 lb

Under the hood

Puma 2303

Mechanical cutting angle control

Up to 110º adjustment of cutting angle through the top bar

Oil flow divider

Longer life for the oil engine

Automatic break-back system

The arm goes backwards if too much pressure is applied from the cutting objective

Counterweights

Stabilize the weight between the Puma 2303 and your vehicle

Foldable arm

Ensures safety when in transport position

Right and left versions

The Puma 2303 is available in right and left versions

Anti-cavitation valve

Minimize the risk of cavitation damage in connection with insufficient inlet pressure

Mounting brackets

Wide variety of solutions for tractors, loaders and excavators

Equipment

Automatic break-back system

Protects the machine from overloading when cutting large material

The break-back system consists of a mounted cylinder connected to an accumulator. The accumulator works by ensuring a soft return of the cylinder piston, so that no recoil effect occurs when the oil pressure in the cylinder is affected.

Expand all equipment

Equipment

Hydraulic cutting angle control (Optional)

Change cutting angle on the go

The hydraulic cutting angle control makes it possible to adjust the angle of the attachment tool via the vehicle's hydraulic control. The attached tool on the Puma 2303 can be adjusted between -20° (vertical position) and 90° (horizontal position).

Expand all equipment

Standard equipment

The Multi Carrier is the most road safe solution on the market

Automatic Hydraulic Break-back with pre-pressure

Mechanical switch from working to transport position

Mechanical cutting angle control

Quick release, hydraulic

Quick release, mechanical

Puma 2303 standard equipment – Oil flow divider

Oil flow divider, 25 l/min (6.6 gpm)

Anti-cavitation valve

1.5 m (4'11") hose kit for attachment tool

Puma 2303 standard equipment – Right or left versions

The Multi Carrier is available for right or left mounting

Euro brackets

The support legs provide stability for quick mounting and dismounting

Optional equipment

Cutting angle, hydr. Puma 2303 S (OPTE1312)

Cutting angle, mech. Puma 2303 S m. hoses (OPTE1311)

Counterweights, Puma 2303, 50 kg (OPTE4293)

Electric remote control

Hosekit Puma 2303 S&P 8,5 m (3 pcs) (OPTE4328)

Mounting

Loader bracket Puma 2303 / Volvo L20F (OPTE577.8)

Loader bracket Puma 2303 / Eurohitch (OPTE4000)

Loader bracket Puma 2303 / Schäffer old (OPTE4001)

Loader bracket Puma 2303 / Schäffer Tele (OPTE4002)

Loader bracket Puma 2303 / Avant (OPTE4003)

Loader bracket Puma 2303 / Weidemann Hydr. (OPTE4004)

Loader bracket Puma 2303 / Trima (OPTE4005)

Loader bracket Puma 2303 / Giant (OPTE4006)

Loader bracket Puma 2303 / Skid steer (OPTE4007)

Loader bracket Puma 2303 / Schäffer small (OPTE4008)

Loader bracket Puma 2303 / Kramer "Small" (OPTE4010)

Loader bracket Puma 2303 / Stensballe/Timan (OPTE4011)

Loader bracket Puma 2303 / JD Compact frontloader (OPTE4012)

Loader bracket Puma 2303 / A- Frame (OPTE4013)

Loader bracket Puma 2303 / Stiegel/Uni loader (OPTE4014)

Loader bracket Puma 2303 / Case 221F (OPTE4015)

Loader bracket Puma 2303 / Mailleux (OPTE4016)

Loader bracket Puma 2303 / CAT 908M (OPTE4019)

Loader bracket Puma 2303 / Liebherr (OPTE4021)

Loader bracket Puma 2303 / Volvo L30-L35 (OPTE4058)

Loader bracket Puma 2303 / CAT906H (OPTE4138)

Universal plate Puma 2303 (OPTE4271)

Loader bracket Puma 2303 / Thaler new (OPTE4277)

Loader bracket Puma 2303 / Thaler old (OPTE4279)

Loader bracket Puma 2303 / Kramer special (OPTE4285)

Equipment overview

Mechanical cutting angle control	Standard
Mechanical switch from working to transport position	Standard
Stand for vertical dismounting	Standard
Automatic Hydraulic Break-back with pre-pressure	Standard
Oil flow divider	Standard
Anti-cavitation valve	Standard
Pressure relief valve	Standard
1.5 m (4'11") hose kit for attachment tool	Standard
Hydraulic and mechanical quick release (integrated on Puma 2303)	Standard
Euro brackets or universal plate	Standard
Hydraulic angle control*	Optional
Hydraulic angle control incl. electric remote control**	Optional
Counterweights, 50 kg (110 lb)	Optional
8.5 m (27'11") hose kit (from front loader to tractor rear) - 3 pcs.	Optional
8.5 m (27'11") hose kit (from front loader to tractor rear) - 5 pcs.	Optional
Other bracket types	Optional

* Hydraulic angle control requires two DA connections. Cannot be retrofitted.
** When you buy the hydraulic angle control and the e-control with an oil flow divider, you only need one DA connection (and a zero-pressure tank drain where it is required).

Models

9992303R-25S

Puma 2303 (25 l/min), right

9992303L-25S

Puma 2303 (25 l/min), left

9992303R-25P

Puma 2303 (25 l/min), right, incl. electric remote control

9992303L-25P

Puma 2303 (25 l/min), left, incl. electric remote control

Technical documents

Name

File type

Puma 2303 S&P Parts

pdf, 1.71 MB

Download

OPTE4251 – Loader bracket HXF2802-Puma2803-3303 S&P&T / Kramer spe.

pdf, 76.90 KB

Download

OPTE4285 – Loader bracket HXF2302-Puma2303 S&P / Kramer special

pdf, 77.65 KB

Download

1...

Sales material

Name

File type

Puma 2303 – Videos

zip, 49.82 MB

Download

Puma 2303 – Work images

zip, 176.93 MB

Download

Puma 2303 – Transparent images

zip, 130.74 MB

Download

FAQ

General questions

We sell our products through a network of dealers. We encourage you to contact your local GreenTec dealer for more information.

If you need any sales advice or cannot find a dealer near you, feel free to contact us on telephone: +45 75553644 or e-mail: sales@greentec.eu

We are available Monday to Thursday from 08.00 - 16.00 CET and Friday from 08.00 - 15.00 CET.

All products are manufactured in Denmark at our production facilities which consist of 5,500 m². We have employees welding components, assembling machines and checking features before the product is shipped to the customer.

We love to give customers a tour of our factory. If you are planning a visit to Denmark, you can schedule an appointment through e-mail: sales@greentec.eu

Our dealers sometimes do demonstrations. You must contact your local GreenTec dealer and ask if they have any upcoming demonstrations.

You cannot rent GreenTec machines directly through us.

We encourage you to contact your local GreenTec dealer to get a list of customers that might be able to offer this service.
